These pumps are true universal talents: Set up underwater they perform their work as submersible motor-driven pumps. They work just as reliably if they are set up in a separate pump chamber.

The robust wet-running canned motors have static seals. In rushing water poses no problem
for these pumps because they can be submersed. In addition thanks to the high-quality materials, such as special ceramics, stainless steel, and tombac, they are durable and offer an extremely long service life.

Product characteristics at a glance
• Suitable for wet and dry installations
• Robust wet-running canned motor
• Wear-free static seals
• Bearings and motor shaft are made of special ceramics
• Shaft, can and pump impeller are made of stainless steel
• Housing made of corrosion resistant tombac alloy

Warranty: 1 year

Specifications

Order no.: 55720
Dimensions: 512L x 180W x 220H mm
Voltage: 3×400 V/ 50 Hz
Power output: 0.49 KW
Current: 0.95 A
B: 180 mm
B1: 140 mm
B2: 178 mm
DD: 1 ½: inch
DS: 2 inch
D: 130 mm
H: 80 mm
H1: 220 mm
L: 512 mm
L1: 268 mm
L2: 244 mm
L3: 33 mm
L4: 297 mm
Cable length: 10 m
Materal: Tombac/ stainless steel 1.4301 . Brass (AISI 304 )
Weight: 22 kg

Pictures

Download Documents

Brochure: USP 413 D
